Cleaning and maintenance

Note: Make sure the appliance is switched off and

unplugged before you start to clean it.

Never use scouring pads, abrasive cleaning agents or

aggressive liquids such as petrol or acetone to clean the

appliance.

Never rinse the appliance or the adapter under the

tap (Fig. 15).

Keep the appliance and the adapter dry (Fig. 16).

Cleaning the attachments

1 Remove the hair-lifting attachment with massage

element from the epilating head (Fig. 17).

Remove the shaving head comb attachment by

pulling it off the shaving head (Fig. 18).

2 Remove loose hairs from the attachments.

3 Rinse the attachments under the tap while turning

them.

4 Dry the attachments before you use or store them.

Cleaning the epilating head

1 Push the epilating head in the direction of the

arrows on the back of the appliance (1) and remove

it (2) (Fig. 9).

2 Remove loose hairs with the cleaning

brush (Fig. 19).

3 Rinse the epilating head under the tap for 5-10

seconds while turning it (Fig. 20).

4 Shake the epilating head rmly (Fig. 21).

Dry the epilating head thoroughly with a tea towel.

Note: Make sure the epilating head is completely dry before

you place it back onto the appliance.

Cleaning the shaving head

1 Push the shaving head in the direction of the

arrows on the back of the appliance (1) and remove

it (2). (Fig. 22)

2 Remove the shaving foil from the shaving

head. (Fig. 23)

3 Rinse the shaving foil and the inside of the shaving

head under the tap for 5-10 seconds while turning

them (Fig. 24).

4 Shake the shaving foil and shaving

head rmly (Fig. 25).

Dry the shaving foil and shaving head thoroughly with a

tea towel.

Note: Do not exert any pressure on the shaving foil to avoid

damage.

Note: Make sure the shaving foil and shaving head are

completely dry before you place it back onto the appliance.

5 Put the protection cap on the shaving head.

Tip: Rub a drop of sewing machine oil onto the shaving foil

twice a year.

Replacement

All parts of the appliance can be replaced. If you need to

replace one or more of the following parts, go to your

Philips dealer or an authorised Philips service centre:

appliance itself

epilating head

hair-lifting attachment with massage element

shaving head

shaving comb

cleaning brush

adapter

Environment

Do not throw away the appliance with the normal

household waste at the end of its life, but hand it in

at an ofcial collection point for recycling. By doing

this, you help to preserve the environment (Fig. 26).

-

-

-

-

-

-

-

-

-

-

-

Guarantee & service

If you need service or information or if you have a problem,

please visit the Philips website at www.philips.com or

contact the Philips Consumer Care Centre in your

country (you nd its phone number in the worldwide

guarantee leaet). If there is no Consumer Care Centre in

your country, go to your local Philips dealer.

Troubleshooting

This chapter summarises the most common problems

you could encounter with the appliance. If you are unable

to solve the problem with the information below, contact

the Consumer Care Centre in your country.

Problem Cause Solution

Poor epilating

results.

You move the

appliance in

the wrong

direction.

Move the appliance against

the direction of hair growth,

with the on/off slide

pointing in the direction

in which you move the

appliance.

You place

the epilating

head on the

skin at the

wrong angle.

Make sure that you place

the appliance on the

skin at an angle of 90°

(see chapter ‘Using the

appliance’).

You used a

(depilatory)

cream prior

to epilation.

Make sure your skin is

clean, entirely dry and free

from grease. Do not use

any cream before you start

epilating.

The hairs are

too short.

Sometimes hairs are too

short to be caught. The

optimal length for easy

removal of the hairs is 3-

4mm. The hairs that are not

caught during this session

will be long enough to be

removed when you epilate

the next time. You can also

try to catch the hairs by

moving the appliance across

the skin a few more times.

The appliance

does not work.

The socket

to which the

appliance is

connected is

not live.

Make sure the socket is

live. If you have connected

the epilator to the socket

in a bathroom cabinet, you

may need to switch on the

bathroom light to activate

the socket.

I cannot

select speed

setting II.

The shaving

head is

attached. The

shaving head

can only be

used at speed

setting I.

Select speed setting I when

you use the shaving head.

I cannot

remove the

shaving

head/epilating

head from the

appliance.

You try to

pull it straight

off.

Push the epilating

head/shaving head in the

direction of the arrows

on the back of the

appliance before you pull

it off the appliance (see

chapter ‘Cleaning and

maintenance’).

4203.000.6185.1

3/5
